Vista de página 0
FFeeaattuurreess
•
1 Port RS422/485
•
Universal PCI
•
128 Byte FIFO with user definable trigger
level
•
Up to 921,600 baud
•
Low Profile and Standard Profile Options
•
Full Duplex and Half Duplex Autogating
•
Transient Spike Protection
•
Drivers for all popular
operating systems
•
Sample Programs, Test &
Terminal software - all with source code
•
Lifetime Support and Lifetime Warranty
Click on each feature to find similar products
OOppttiioonnss
UNIVERSAL 1 PORT VELOCITY RS422/485
TEL: +44
(
0
)
151 220 2500 EMAIL: [email protected] WEB: WWW.BRAINBOXES.COM
DDeessccrriippttiioonn
Universal PCI card providing 1 industry standard 9 pin
RS422/485 serial COM port in a single PCI slot. On-board Zener
diodes ensure electrical protection. Velocity megabaud data
transfer rates and 128 byte deep FIFO guarantees
uncompromising performance and fault-free use.
Available as a standard Profile or Low Profile card. Low Profile is
the industry standard small form factor design for PCI.
Universal PCI is fully compatible with both 3.3Volt and 5Volt
PCI slots; protecting your investment into the future.
Now with Brainboxes Lifetime Warranty and Lifetime Support!
SSooffttwwaarree
Microsoft signed drivers (easy installation & robust operation) for:
o Windows Server 2003 x32 bit & x64 bit Editions
o Windows XP x32 bit & x64 bit Editions
o Windows 2000.
Fully tested drivers also included for:
o Windows Me, Windows 98 & 95, Windows NT.
As well as: full product documentation, a thorough troubleshooting
guide and terminal software. Detailed sample source code for all
popular programming languages.
Need support for other operating systems? Please telephone or email.
Find out about Brainboxes excellent driver configurability: Click Here
ORDER
Description Code
UNIVERSAL LOW PROFILE 1 PORT VELOCITY RS422/485 UC-320
UNIVERSAL 1 PORT VELOCITY RS422/485 UC-324
UC-320 & UC-324
SERIAL CARDS ENGINEERED TO EXCEED EXPECTATIONS
Low Profile: UC-320
Standard Profile:
UC-324
RoHS Compliant
Vista de página 0
1 2 3 4

Resumo do Conteúdo

Página 1 - UC-320 & UC-324

FFeeaattuurreess•1 Port RS422/485•Universal PCI •128 Byte FIFO with user definable triggerlevel•Up to 921,600 baud•Low Profile and Standard Profile Op

Página 2 - Pinout (9 pin Male)

UNIVERSAL 1 PORT VELOCITY RS422/485Product Code UC-320 & UC-324Serial PortPorts 1 Port RS422/485Connector DB9 (9 Pin Male)UART type 16950 UART ins

Página 3 - LLooww PPrrooffiillee

UNIVERSAL 1 PORT VELOCITY RS422/485Glossary: Product Features ExplainedUniversal PCIUniversal products allow compatibility with both 3.3 Volt and 5 Vo

Página 4 - TEL: +44

UNIVERSAL 1 PORT VELOCITY RS422/485TEL: +44 (0)151 220 2500 EMAIL: [email protected] WEB: WWW.BRAINBOX
